- Heavy Duty 12,000kg Agricultural trailer designed to satisfy the requirements of modern trailer operations.
- All chassis and body parts are manufactured from high tensile steel plate and hollow section to help reduce weight and increase payload without compromising structural strength
- Unique design sprung draw bar provides excellent ride characteristics working in combination with the multi leaf spring bogie suspension to reduce stress on the towing vehicle and operator.
- Tapered body and twin heavy duty tipping rams ensure a fast and clean unloading time with all hydraulic pipes safely concealed within the chassis.
- 8 stud heavy duty axle, brakes and lights.
- 40mm EN8 towing eye, skid and skid carrier Hydraulic hose carrier and access ladder. 550/45/22.5 as standard

Options include:
- Hydraulic back door complete with locking safety valve to avoid accidental spillage.
- Galvanised silage extension kit complete with swinging back door and automatic trip.
385/65/22.5 (super singles) in lieu of 550/45/22.5 Front viewing window
-Tarpaulin cover
-Grain chute

OPTIONS INCLUDE

- Hydraulic back door complete with locking safety valve to avoid accidental spillage

- Galvanised silage extension kit complete with swinging back door and automatic trip

- 550/45/22.5 flotation tyres

- Front viewing window

- Grain chute

- Tarpaulin cover

SPECIFICATION (TRF25):
Floor Thickness - 4mm
Body Length - 7.6m
Width - 2.44m
Loading Height - 1.2m
Lights - Yes
Brakes - Yes
Unladen Weight - 2880kg
Wheel Size Standard - 385 x 65 x R225
Wheel Size Optional - 500 x 45 x 22.5
